290AC Certificación ISO 9000

290AC

Evo Line

EVO line offers an ambitious range of tractors and agricultural machinery, with an optimal quality/price ratio, so that each producer can have the strength of a Pauny in their field.

Tractors with Assisted Traction, Articulated Double Traction and Total Traction P-Trac, with variants of power and motor, cover a wide range of requirements for large extensions of field, with low consumption per hectare worked and maximum tractive force for better performance.
More about this product

080077 PAUNY (72869)

Technical specifications

Engine

Brand/Model:
Cummins 6BTA 5,9

Power:

Engine power at rated speed kw (HP):
130 (174)

Type:
Diesel 4 times.

Maximum rated speed (rpm):
2500

Maximum torque (Nm):
637

Maximum torque pattern (rpm):
1500

Number of cylinders:
6

Displacement (cm3):
5883

Aspiration:
Turbo supercharged after-cooled

Diameter / Stroke (mm):
100/120

Compression ratio:
18:1

Injection:
Linear pump

Cooling system:
By liquid under pressure, with thermostat

Starting system:
Electric 12 V, with ignition key

Torque reserve (%):

Minimum consumption (g / kw.h):

Lubrication:

Air filter:

Exhaust system:

Transmission

Type:
Helical gear, synchronized

Gearbox:
12 forward and 4 reverse speeds

Front axle:
Directional, tractive

Rear axle:
Mechanical drive lock

Pressure of the steering system (mpa):

Speeds:

Brand:

Model:

Differential lock (NoSPin):

Torque ratio:

Maximum input speed (r.p.m.):

Maximum allowable engine torque (Nm):

Clutch

Type:
Bidisc transmission. PTO / Multidisc

Disc diameter: PTO / Transmission
13" (342 mm). In oil bath

Hydraulic System

Type:
Closed center (Load sensing), with a 63 cm3/rev piston pump

Maximum flow rate (l / min):
157,5L/min. at 2500rpm

Flow rate (l / min):

Maximum working pressure (bar):
180

Working pressure (Mpa):

Steering system pressure (Mpa):

Relief pressure:

Hydraulic outlets:

Fluid reservoir:
Independent

Steering hydraulics:

Hydraulic cylinders:

Filter system:
Metallic filter in suction + 1 micron paper in return

Valve bank:

Electric System

Voltage (V):
12 V

Alternator (A):
12 V, 130 A

Battery (Ah):
1 (one) of 12 V and 180 A

Power Take-Off

Type:
Independent, electro-hydraulic coupling

PTO Speed:
540 and 1000 rpm

Drawbar:

Capacities and Weight

Fuel tank (reservoir) (l):
270

Tank with front PTO:

Auxiliary tank:

Hydraulic fluid tank (l):
85

Crankcase included oil filter (l):
12,5

Gearbox (l):

Rear differential (l):

Gearbox and rear differential (l):
95

Front differential (l):
11

Transmission (l):

Transmission (kg):

Transmission and rear differential (l):

Front axle (differential / hubs):

Weight without ballast in start command (kg):
6050

Weight with ballast with water in the covers and full fuel tank (kg):
7380

Nominal load (kg):

Operating weight (kg):

Bucket capacity (l):

Traction cycle time:

Maximum tractive force (kN):

Maximum displacement force:

Front wheel hub each (l):

Lubricant capacity (without radiator) (l):

Base machine weight (kg):

Front axle (kg):

Rear axle (kg):

Maximum weight (kg):

Total cycle time (s):

Articulation and Pivoting

Type:

Steering angle (°):

Articulation angle (°):

Minimum turning radius (mm):

Total pivoting angle (°):

Brakes

Service brakes:
Mechanical drive

Parking brakes:
Mechanical drive

Traction

Simple / Double:
Double

Tire Sizes

Front / Rear:

Front :
16,9 x 30

Rear:
24,5 L x 32

Type:

Tires:

Rims:

Chassis

Type of chassis:

Operator´s Station

Type:

Steering:
Hydrostratic, sensitive (Load Sensing)

Cabin:
Pressurized, which prevents the entry of particles. With A/C hot/cold. Steering column: adjustable in height and depth, steering column break: 1 point forward and one backward, to obtain the best driving position

Characteristics of the steering column:

Board:
Analog compact, with indic. of: engine rpm, oil pressure, coolant temperature, fuel level. Indicate lights: low oil pressure, clogged air filter, over coolant temperature, low fuel level, parking brake engaged, alternator failure, PTO engaged, lights

Light switch:
Single control waterproof keyboard

Seat:
Anatomical, with longitudinal, vertical and operator weight adjustment

Dimensions

Axle spacing (mm):
2929

Total dimension (mm):

Total length (mm):
5164

Maximum height (mm):
3015

Max. dumping height (mm):

Dumping reach (mm):

Ground clearance (mm):

Height at the steering (mm):

Minimum wheel track (mm):

Maximum wheel track (mm):

Maximum single wheel track (mm):

Front wheel track (mm):
2000 / 2100

Rear wheel track (mm):
2150

Wheel track (mm):

Maximum width (mm):

Total width with single wheels (mm):

Total width with dual (mm):

Max single / dual width (mm):

Length with bucket (mm):

Total width (mm):
2725

Maximum single / dual wheel track (mm):

Maximum wheel track with dual (mm):

Maximum height at the steering (mm):

Travel Speed

Travel speed - Forward km/h):

Travel speed - Reverse (km/h):

Axles

Front axle:

Rear axle:

Front Loader Capacities

Bucket capacity - struck (m3):

Bucket capacity - heaped (m3):

Loading reach (m):

Dumping height (m):

Total operating height (m):

Turning angle (°):

Dumping angle (°):

Backhoe Capacities

Reach from central articulation (m):

Loading reach (m):

Operating height (m):

Digging depth (m):

Digging depth with flat bottom (m):

Arm folding force (kgf):

Turning arc (°):

Bucket penetration force (kgf):

Standard bucket width:

Loading height (m):

Operational Data

Transport height (m):

Transport width (m):

Transport length (m):

Axle spacing (m):

Cabin height (m):

Operating weight (kg):

Lights

Front Lights:

Rear Lights:

Attachment

Hydraulic lift
(Three point hitch):

Drawbar:

Category:

Lower Boards:

Other

Traction:

Ballast:

Standard Equipment

Backup Camera:

Hydraulic decoupling of the bucket from the cab:

Lights for night work:

Air conditioning:

Third hydraulic way for bale spear:

Hydraulic joystick:

Tandem

Type:

Thickness (mm):

Chain drive step (mm):

Axle spacing (mm):

Oscillation (°):

Type of bearings:

Moldboard

Tipo:

Dimensiones (mm):

Presión máxima de la hoja (eq. estándar)(kg):

Alcance máximo por fuera de las ruedas (mm):

Ángulo máximo para corte de talud (°):

Operaciones:

Elevación de la cuchilla:

Desplazamiento lateral:

Inclinación de la hoja:

Máxima elevación sobre el suelo (mm):

Desplazamiento lat. del centro del circulo (mm):

Desplazamiento lat. de la vertedera (mm):

Cantoneras:

Rieles:

Scarifier

Number of teeth:

Working width (mm):

Drawbar:

Ripper:

Circle

Type:

External diameter (mm):

Rotation (continuous) (°):

Supports:

Thickness (mm):

Circle drive:

Frontal excavator blade

Type:

Compactor wheels

Type:

Extra Equipment

Mud scraper kit:

Full lower enclosure:

Hydraulic tank enclosure:

Optional Elements

3 point hydraulic lift:

Rear hitch for trailer:

Air conditioner:

Sunshade roof:

Closed cabin:

Hydraulic elevator:

Counterweight:

Hydraulic equipment:

Drawbar:
