ECOFRIENDLY 500

Vial Line

Discover the force that opens paths. Pauny Vial Line, a large park of machinery for construction work, improvement and maintenance of routes and streets, earthmoving, compaction and leveling of soils, asphalting, excavations, clearing, ditching and sanitation, among others.

The series includes all the variables to work safely, optimize times and facilitate the machinery transfer.

Robust, agile, with high durability and performance in the most diverse areas, the Pauny tractors provide ease of handling, excellent visibility and the confidence demanded by the most demanding projects.

More about this product

080077 PAUNY (72869)

Technical specifications

Engine

Brand/Model:
Cummins / 6CT 8.3

Power:

Engine power at rated speed kw (HP):
149 (200)

Type:
Diesel 4 times.

Maximum rated speed (rpm):
2200

Maximum torque (Nm):
769 (78,38)

Maximum torque pattern (rpm):
1500

Number of cylinders:
6

Displacement (cm3):
8267

Aspiration:
Turbo supercharged.

Diameter / Stroke (mm):
114 / 135

Compression ratio:
17,3:1

Injection:
Direct. Linear pump.

Cooling system:
By liquid under pressure, with thermostat. With deaeration system.

Starting system:
Electric 12 V, with ignition key, safety switch and fuse.

Torque reserve (%):

Minimum consumption (g / kw.h):
202 to 1600 rpm

Lubrication:
Forced by pressure with oil heat exchanger.

Air filter:
Dry type with filter elements with safety cartridges.

Exhaust system:
Virtual exhaust pipe with silencer.

Transmission

Type:
With torque converter ZF ERGO POWER WG160 Power Shift type, commanded via joystick in sequential or automatic manual mode. 6 speeds box.

Gearbox:

Front axle:
Epicyclic-type final reduction. Internal, next to the differential gear. Number of satellites: three (3). Transmission ratio: 6:1. Ring gear and pinion ratio 5.5:1.

Rear axle:
Epicyclic-type final reduction. Internal, next to the differential gear. Number of satellites: three (3). Transmission ratio: 6:1. Ring gear and pinion ratio 5.5:1.

Pressure of the steering system (mpa):

Speeds:

Brand:

Model:

Differential lock (NoSPin):

Torque ratio:

Maximum input speed (r.p.m.):

Maximum allowable engine torque (Nm):

Clutch

Type:

Disc diameter: PTO / Transmission

Hydraulic System

Type:
Open center with external gear pump.

Maximum flow rate (l / min):
98 at 2200 rpm of the engine.

Flow rate (l / min):

Maximum working pressure (bar):
180

Working pressure (Mpa):

Steering system pressure (Mpa):

Relief pressure:

Hydraulic outlets:
3 outputs for double-effect cylinders.

Fluid reservoir:
Independent.

Steering hydraulics:

Hydraulic cylinders:

Filter system:
With metallic mesh filter at the outlet of the reservoir and 10 micron paper filter in the return.

Valve bank:

Electric System

Voltage (V):
24 V, with negative to ground.

Alternator (A):
24 V, 90 A, with built-in voltage regulator.

Battery (Ah):
One (1) of 24 V and 180 Ah.

Power Take-Off

Type:
Manual mechanical drive. Rated speed 540 rpm. / Opt.: 1000 rpm.

PTO Speed:

Drawbar:
Ventral type of barycentric arrangement. Fixed with ball joints in the articulation, with rollers for lateral movement.

Capacities and Weight

Fuel tank (reservoir) (l):
425

Tank with front PTO:

Auxiliary tank:

Hydraulic fluid tank (l):
130

Crankcase included oil filter (l):
20

Gearbox (l):
18

Rear differential (l):
55

Gearbox and rear differential (l):

Front differential (l):
45

Transmission (l):

Transmission (kg):

Transmission and rear differential (l):

Front axle (differential / hubs):

Weight without ballast in start command (kg):

Weight with ballast with water in the covers and full fuel tank (kg):

Nominal load (kg):

Operating weight (kg):
18/20

Bucket capacity (l):

Traction cycle time:

Maximum tractive force (kN):

Maximum displacement force:

Front wheel hub each (l):

Lubricant capacity (without radiator) (l):

Base machine weight (kg):

Front axle (kg):

Rear axle (kg):

Maximum weight (kg):

Total cycle time (s):

Articulation and Pivoting

Type:
Through three-point support; ball joint with articulation and pivoting.

Steering angle (°):
70° (± 35° from the center)

Articulation angle (°):

Minimum turning radius (mm):

Total pivoting angle (°):
30° (± 15° from the center)

Brakes

Service brakes:
Disc on transmission output, with hydraulic drive.

Parking brakes:
Commanded by lever on the service brake.

Traction

Simple / Double:

Tire Sizes

Front / Rear:

Front :

Rear:

Type:

Tires:

Rims:

Chassis

Type of chassis:

Operator´s Station

Type:

Steering:
Sensitive hydrostatic, on the joint.

Cabin:
Anti-roll, hermetic and soundproof, mounted on anti-vibration rubber blocks. With A/C cold/heat. Steering column adjustable in height and depth, to obtain the best driving position.

Characteristics of the steering column:
Light switch incorporated into the steering column.

Board:
Compact digital, with digital indicators of: engine rpm, oil pressure, cooling temperature, fuel level.

Light switch:
Light switch incorporated into the steering column.

Seat:
Anatomical, with regulation in all directions.

Theoretical Speeds

Dimensions

Axle spacing (mm):

Total dimension (mm):

Total length (mm):

Maximum height (mm):

Max. dumping height (mm):

Dumping reach (mm):

Ground clearance (mm):

Height at the steering (mm):

Minimum wheel track (mm):

Maximum wheel track (mm):

Maximum single wheel track (mm):

Front wheel track (mm):

Rear wheel track (mm):

Wheel track (mm):

Maximum width (mm):

Total width with single wheels (mm):

Total width with dual (mm):

Max single / dual width (mm):

Length with bucket (mm):

Total width (mm):

Maximum single / dual wheel track (mm):

Maximum wheel track with dual (mm):

Maximum height at the steering (mm):

Travel Speed

Travel speed - Forward km/h):

Travel speed - Reverse (km/h):

Axles

Front axle:

Rear axle:

Front Loader Capacities

Bucket capacity - struck (m3):

Bucket capacity - heaped (m3):

Loading reach (m):

Dumping height (m):

Total operating height (m):

Turning angle (°):

Dumping angle (°):

Backhoe Capacities

Reach from central articulation (m):

Loading reach (m):

Operating height (m):

Digging depth (m):

Digging depth with flat bottom (m):

Arm folding force (kgf):

Turning arc (°):

Bucket penetration force (kgf):

Standard bucket width:

Loading height (m):

Operational Data

Transport height (m):

Transport width (m):

Transport length (m):

Axle spacing (m):

Cabin height (m):

Operating weight (kg):

Lights

Front Lights:

Rear Lights:

Attachment

Hydraulic lift
(Three point hitch):

Drawbar:

Category:

Lower Boards:

Other

Traction:

Ballast:

Standard Equipment

Backup Camera:

Hydraulic decoupling of the bucket from the cab:

Lights for night work:

Air conditioning:

Third hydraulic way for bale spear:

Tandem

Type:

Thickness (mm):

Chain drive step (mm):

Axle spacing (mm):

Oscillation (°):

Type of bearings:

Moldboard

Tipo:

Dimensiones (mm):

Presión máxima de la hoja (eq. estándar)(kg):

Alcance máximo por fuera de las ruedas (mm):

Ángulo máximo para corte de talud (°):

Operaciones:

Elevación de la cuchilla:

Desplazamiento lateral:

Inclinación de la hoja:

Máxima elevación sobre el suelo (mm):

Desplazamiento lat. del centro del circulo (mm):

Desplazamiento lat. de la vertedera (mm):

Cantoneras:

Rieles:

Scarifier

Number of teeth:

Working width (mm):

Drawbar:

Ripper:

Circle

Type:

External diameter (mm):

Rotation (continuous) (°):

Supports:

Thickness (mm):

Circle drive:

Frontal excavator blade

Type:
3 m working width and 1.3 m height. Powered by two double-effect hydraulic cylinders.

Compactor wheels

Type:
Crow bar, built entirely in blade 3/8” (can be ballasted to increase the operational weight of the machine).

Extra Equipment

Mud scraper kit:
Adjustable in depth, built in 38 mm billet.

Full lower enclosure:
From the tube to the joint, in 8 mm thick blade metal.

Hydraulic tank enclosure:
Closing of the hydraulic tank.

Optional Elements

3 point hydraulic lift:

Rear hitch for trailer:

Air conditioner:

Sunshade roof:

Closed cabin:

Hydraulic elevator:

Counterweight:

Hydraulic equipment:

Drawbar:
