Cummins / QSB 6.7 TIER 3
200 BHP/150 kW @ 2300 rpm
Engine power at rated speed kw (HP):
Maximum rated speed (rpm):
Maximum torque (Nm):
882/89.90 kgf m @ 1500 rpm
Maximum torque pattern (rpm):
Diameter / Stroke (mm):
107 / 124
Minimum consumption (g / kw.h):
Transmission with torque converter ZF ERGO POWER WG160 Power Shift type, commanded via joystick in sequential or automatic manual mode. It presents a protection system against operation and maintenance errors, such as direction of travel reversal, excess speed, obstruction of the lubrication filter and excess torque, among others. It has a digital display for speed indication and fault monitors, as well as a digital thermometer to control the oil temperature of the box.
Pressure of the steering system (mpa):
Differential lock (NoSPin):
Maximum input speed (r.p.m.):
Maximum allowable engine torque (Nm):
Closed center, with variable flow piston pump, coupled to the gearbox.
Maximum flow rate (l / min):
140 @ 2200 rpm
Maximum working pressure (bar):
Steering system pressure (Mpa):
Hydrostatic type, Load Sensing system with priority valve. It can be operated with the motor stopped (acting as a pump).
Double-effect, chromed and rectified rods.
Triple (load, suction and return), with washable and replaceable elements.
24 V, 2 batteries connected in series of 110 Ah each.
Capacities and Weight
Fuel tank (reservoir) (l):
Hydraulic fluid tank (l):
Crankcase included oil filter (l):
Gearbox and rear differential (l):
Transmission and rear differential (l):
Front axle (differential / hubs):
Weight without ballast in start command (kg):
Weight with ballast with water in the covers and full fuel tank (kg):
Maximum tractive force (kN):
Maximum displacement force:
Front wheel hub each (l):
Lubricant capacity (without radiator) (l):
Base machine weight (kg):
Front axle (kg):
5205 (with base machine weight) / 5850 (with maximum weight).
Rear axle (kg):
12145 (with base machine weight) / 13650 (with maximum weight).
Maximum weight (kg):
Articulation and Pivoting
Articulation angle (°):
20° (both sides)
Minimum turning radius (mm):
Total pivoting angle (°):
Hydraulically drive. They work through internal discs in oil immersion, housed inside the differential gear housing. They also have accumulators, which allow braking the machine in case of pressure drop in the brake’s hydraulic system or diesel engine stop. Pedal drive, piston-type pump, pump flow 80 l/min.
Automatic-type, independent of system pressure; this allows the brake to be actuated when the motor stops or there is a pressure drop. Manual operation by means of lever. It also has a protection device, which prevents the movement of the machine with the parking brake applied.
On the right side there is a console where the speed selector is mounted, control box display, hand accelerator and the rest of the lighting keys.
Hydrostatic, with Load Sensing system and priority valve.
AA - heating - radio with CD/MP3.
Characteristics of the steering column:
Screen that shows information of the engine and box, and panel with light alerts.
Adjustable in height and depth.
Nodular cast iron housing with ribs located to withstand stresses to which it is subjected. Propulsion by gear and chain.
Chain drive step (mm):
20° (both sides).
Type of bearings:
3978 x 660 x 19
Presión máxima de la hoja (eq. estándar)(kg):
Alcance máximo por fuera de las ruedas (mm):
Left side: 1810 / Right side: 1970
Ángulo máximo para corte de talud (°):
Elevación de la cuchilla:
2 cylinders Ø 89 mm
1 cylinder Ø 89 mm
Inclinación de la hoja:
Forward: 45° / Backward: 5°.
Máxima elevación sobre el suelo (mm):
Forward: 45° / Backward: 5°.
Desplazamiento lat. del centro del circulo (mm):
Right: 670 / Left: 500
Desplazamiento lat. de la vertedera (mm):
Right: 1300 / Left: 1300
Of displacement supported in polyamide bearings.
A-shaped, welded in a single piece. Dimension: 170 x 38.1 mm.
Number of teeth: 3 - Working width: 1696 mm - Depth of work: 410 mm.
Built in square section of high strength steel.
External diameter (mm):
Rotation (continuous) (°):
Wormgear box driven by hidraulic motor.
