ARTICULATED 580

Novo Line

With all the support of the strength from the majority, Pauny bursts with its line of high-end articulated tractors NOVO. Powerful, unconditional, they are equipped with the emblematic and efficient 4-stroke Cummins engine and a Load Sensing closed-center hydraulic system. The series comes with a great impact design and superior comfort.

Thanks to the innovative design of the panoramic cabin and the maximum comfort for the driver, the NOVO Pauny turns the extensive days of rural work into a truly enjoyable experience.

More about this product

080077 PAUNY (72869)

Technical specifications

Engine

Brand/Model:
Cummins / 6CTAP 8.3 C

Power:

Engine power at rated speed kw (HP):
195 (260)

Type:

Maximum rated speed (rpm):
2200

Maximum torque (Nm):
1021 (104,07)

Maximum torque pattern (rpm):
1500

Number of cylinders:
6 aligned.

Displacement (cm3):
8.267

Aspiration:
Turbo supercharged post-cooled.

Diameter / Stroke (mm):
114 / 135

Compression ratio:
16,5:1

Injection:
Direct. Linear pump.

Cooling system:
By liquid under pressure, with thermostat. With deaeration system.

Starting system:
Electric 12 V, with ignition key, safety switch and fuse.

Torque reserve (%):

Minimum consumption (g / kw.h):

Lubrication:

Air filter:

Exhaust system:

Transmission

Type:
Helical gears in constant shot, with four (4) trees arranged in cascade. Semi-synchronized coupling by internal gears of manual operation by means of three (3) levers.

Gearbox:
Number of speeds: three (3) forward gears and one (1) reverse gear, which combined with the four ranges total twelve (12) forward gears and four (4) reverse gears.

Front axle:
Epicyclic-type final reduction. Internal, next to the differential gear. Number of satellites: three (3). Transmission ratio: 6:1. Ring gear and conical pinion ratio: 5.5:1.

Rear axle:
Epicyclic-type final reduction. Internal, next to the differential gear. Number of satellites: three (3). Transmission ratio: 6:1. Ring gear and conical pinion ratio: 5.5:1.

Pressure of the steering system (mpa):

Speeds:

Brand:

Model:

Differential lock (NoSPin):

Torque ratio:

Maximum input speed (r.p.m.):

Maximum allowable engine torque (Nm):

Clutch

Type:
Dry friction, with independent pedal mechanical drive.

Disc diameter: PTO / Transmission
15'' (380mm) single disc.

Hydraulic System

Type:
Closed center (load sensing), with axial piston pump for variable flow and pressure.

Maximum flow rate (l / min):
112 at 2200 rpm of the engine.

Flow rate (l / min):

Maximum working pressure (bar):
180

Working pressure (Mpa):

Steering system pressure (Mpa):

Relief pressure:

Hydraulic outlets:
3 outputs for double-effect cylinders.

Fluid reservoir:
Independent.

Steering hydraulics:

Hydraulic cylinders:

Filter system:
With metallic mesh filter at the outlet of the reservoir and 10 micron paper filter in the return.

Valve bank:

Electric System

Voltage (V):
12 V, with negative to ground.

Alternator (A):
12 V, 110 A, with built-in voltage regulator.

Battery (Ah):
One (1) of 12 V and 130 Ah.

Power Take-Off

Type:
Manual mechanical drive. Rated speed 540 rpm. / Opt.: 1000 rpm.

PTO Speed:
540 rpm.

Drawbar:

Capacities and Weight

Fuel tank (reservoir) (l):
521

Tank with front PTO:

Auxiliary tank:

Hydraulic fluid tank (l):
130

Crankcase included oil filter (l):
20

Gearbox (l):
18

Rear differential (l):
55

Gearbox and rear differential (l):

Front differential (l):
45

Transmission (l):

Transmission (kg):

Transmission and rear differential (l):

Front axle (differential / hubs):

Weight without ballast in start command (kg):
7244

Weight with ballast with water in the covers and full fuel tank (kg):
10165

Nominal load (kg):

Operating weight (kg):

Bucket capacity (l):

Traction cycle time:

Maximum tractive force (kN):

Maximum displacement force:

Front wheel hub each (l):

Lubricant capacity (without radiator) (l):

Base machine weight (kg):

Front axle (kg):

Rear axle (kg):

Maximum weight (kg):

Total cycle time (s):

Articulation and Pivoting

Type:
Through three-point support; ball joint with articulation and pivoting.

Steering angle (°):
70° (± 35° from the center)

Articulation angle (°):

Minimum turning radius (mm):

Total pivoting angle (°):
30° (± 15° from the center)

Brakes

Service brakes:
Disc on transmission output, with hydraulic drive.

Parking brakes:
Commanded by lever on the service brake.

Traction

Simple / Double:
Double.

Tire Sizes

Front / Rear:
460/85R34 / 460/85R38 / 23.1 x 30 (12 screens) simple and double / 24.5 x 32 (12 screens) simple.

Front :

Rear:

Type:

Tires:

Rims:

Chassis

Type of chassis:

Operator´s Station

Type:

Steering:
Sensitive hydrostatic on the joint.

Cabin:
Anti-roll, hermetic and soundproof, mounted on anti-vibration rubber blocks. With A/C cold/heat. Steering column: adjustable in height and depth, to obtain the best driving position.

Characteristics of the steering column:

Board:
Compact analog, with analog indicators of: engine rpm, oil pressure, cooling temperature, fuel level.

Light switch:
Incorporated into the steering column.

Seat:
Anatomical, with regulations in all directions.

Theoretical Speeds

Dimensions

Axle spacing (mm):
3050

Total dimension (mm):

Total length (mm):
5685

Maximum height (mm):
3620

Max. dumping height (mm):

Dumping reach (mm):

Ground clearance (mm):
550

Height at the steering (mm):

Minimum wheel track (mm):
1680

Maximum wheel track (mm):

Maximum single wheel track (mm):

Front wheel track (mm):

Rear wheel track (mm):

Wheel track (mm):

Maximum width (mm):

Total width with single wheels (mm):
2270 / 2790

Total width with dual (mm):
3650

Max single / dual width (mm):

Length with bucket (mm):

Total width (mm):

Maximum single / dual wheel track (mm):
2200 / 3060

Maximum wheel track with dual (mm):

Maximum height at the steering (mm):

Travel Speed

Travel speed - Forward km/h):

Travel speed - Reverse (km/h):

Axles

Front axle:

Rear axle:

Front Loader Capacities

Bucket capacity - struck (m3):

Bucket capacity - heaped (m3):

Loading reach (m):

Dumping height (m):

Total operating height (m):

Turning angle (°):

Dumping angle (°):

Backhoe Capacities

Reach from central articulation (m):

Loading reach (m):

Operating height (m):

Digging depth (m):

Digging depth with flat bottom (m):

Arm folding force (kgf):

Turning arc (°):

Bucket penetration force (kgf):

Standard bucket width:

Loading height (m):

Operational Data

Transport height (m):

Transport width (m):

Transport length (m):

Axle spacing (m):

Cabin height (m):

Operating weight (kg):

Lights

Front Lights:

Rear Lights:

Attachment

Hydraulic lift
(Three point hitch):

Drawbar:

Category:

Lower Boards:

Other

Traction:

Ballast:

Standard Equipment

Backup Camera:

Hydraulic decoupling of the bucket from the cab:

Lights for night work:

Air conditioning:

Third hydraulic way for bale spear:

Tandem

Type:

Thickness (mm):

Chain drive step (mm):

Axle spacing (mm):

Oscillation (°):

Type of bearings:

Moldboard

Tipo:

Dimensiones (mm):

Presión máxima de la hoja (eq. estándar)(kg):

Alcance máximo por fuera de las ruedas (mm):

Ángulo máximo para corte de talud (°):

Operaciones:

Elevación de la cuchilla:

Desplazamiento lateral:

Inclinación de la hoja:

Máxima elevación sobre el suelo (mm):

Desplazamiento lat. del centro del circulo (mm):

Desplazamiento lat. de la vertedera (mm):

Cantoneras:

Rieles:

Scarifier

Number of teeth:

Working width (mm):

Drawbar:

Ripper:

Circle

Type:

External diameter (mm):

Rotation (continuous) (°):

Supports:

Thickness (mm):

Circle drive:

Frontal excavator blade

Type:

Compactor wheels

Type:

Extra Equipment

Mud scraper kit:

Full lower enclosure:

Hydraulic tank enclosure:

Optional Elements

3 point hydraulic lift:
Yes

Rear hitch for trailer:

Air conditioner:

Sunshade roof:

Closed cabin:

Hydraulic elevator:

Counterweight:

Hydraulic equipment:

Drawbar:
