ASSISTED 280A
Evo Line
EVO line offers an ambitious range of tractors and
agricultural machinery, with an optimal quality/price ratio, so that each
producer can have the strength of a Pauny in their field.
Tractors with Assisted Traction, Articulated Double Traction and Total Traction
P-Trac, with variants of power and motor, cover a wide range of requirements
for large extensions of field, with low consumption per hectare worked and
maximum tractive force for better performance.
More about this product
Technical specifications
Engine
Brand/Model:
CUMMINS / 6 BT 5.9
Power:
Engine power at rated speed kw (HP):
135 (180)
Type:
Diesel 4 times.
Maximum rated speed (rpm):
2500
Maximum torque (Nm):
64.9 (637)
Maximum torque pattern (rpm):
1500
Number of cylinders:
6 aligned.
Displacement (cm3):
5.883
Aspiration:
Turbo supercharged post-cooled.
Diameter / Stroke (mm):
102 / 120
Compression ratio:
17,5:1
Injection:
Direct. Linear pump.
Cooling system:
By liquid under pressure, with thermostat.
Starting system:
Electric 12 V, with ignition key, safety switch and fuse.
Torque reserve (%):
Minimum consumption (g / kw.h):
Lubrication:
Air filter:
Exhaust system:
Transmission
Type:
Helical gears in constant shot. With synchronized coupling by external gears. Manual operation by means of two (2) levers.
Gearbox:
Number of speeds: five (5) forward gears and one (1) reverse gear, which combined with the low and high range total ten (10) forward gears and two (2) reverse gears.
Front axle:
Epicyclic-type final reduction of straight gears. Number of satellites: three (3). Transmission ratio: 6.923:1. Ring gear and pinion ratio 3.10:1. Number of satellites: four (4).
Rear axle:
Epicyclic-type final reduction of straight gears. Number of satellites: 3 (three). Transmission ratio: 6:1. Ring gear and pinion ratio:5:1 (8/44). Number of satellites: four (4). Differential lock with pedal drive and automatic unlocking.
Pressure of the steering system (mpa):
Speeds:
Brand:
Model:
Differential lock (NoSPin):
Torque ratio:
Maximum input speed (r.p.m.):
Maximum allowable engine torque (Nm):
Clutch
Type:
Dual disc dry friction, with independent drive.
Disc diameter: PTO / Transmission
13'' (330 mm). Pedal mechanical drive. 15'' (380 mm). Pedal mechanical drive.
Hydraulic System
Type:
Open center, with external gear pump.
Maximum flow rate (l / min):
80 at 2500 rpm of the engine.
Flow rate (l / min):
Maximum working pressure (bar):
180
Working pressure (Mpa):
Steering system pressure (Mpa):
Relief pressure:
Hydraulic outlets:
2 outputs for double-effect cylinders. / Optional: 3 outputs.
Fluid reservoir:
Independient.
Steering hydraulics:
Hydraulic cylinders:
Filter system:
With metallic mesh filter at the outlet of the reservoir and 10 micron paper filter in the return.
Valve bank:
Electric System
Voltage (V):
12 V, with negative to ground.
Alternator (A):
12 V, 55 A, with built-in voltage regulator.
Battery (Ah):
One (1) of 12 V and 180 Ah.
Power Take-Off
Type:
Connection totally independent of the transmission. Rated speed 540 rpm / Opt.: 1000 rpm.
PTO Speed:
540 rpm.
Drawbar:
Capacities and Weight
Fuel tank (reservoir) (l):
170 / Qty. 2 interconnected.
Tank with front PTO:
Auxiliary tank:
Hydraulic fluid tank (l):
82
Crankcase included oil filter (l):
12,5
Gearbox (l):
Rear differential (l):
Gearbox and rear differential (l):
Front differential (l):
11
Transmission (l):
90 / Included oil filter.
Transmission (kg):
Transmission and rear differential (l):
Front axle (differential / hubs):
Weight without ballast in start command (kg):
6.230
Weight with ballast with water in the covers and full fuel tank (kg):
7,564 / Rear tire 18.4 x 38 dual, 4 rear count., 20 front count. and 10 ventral count.
Nominal load (kg):
Operating weight (kg):
Bucket capacity (l):
Traction cycle time:
Maximum tractive force (kN):
Maximum displacement force:
Front wheel hub each (l):
Lubricant capacity (without radiator) (l):
Base machine weight (kg):
Front axle (kg):
Rear axle (kg):
Maximum weight (kg):
Total cycle time (s):
Articulation and Pivoting
Type:
Steering angle (°):
Articulation angle (°):
Minimum turning radius (mm):
Total pivoting angle (°):
Brakes
Service brakes:
Oil immersed disc, with independent or simultaneous pedal drive.
Parking brakes:
Commanded by manual lever, which acts on the service brake.
Traction
Simple / Double:
Double.
Tire Sizes
Front / Rear:
16,9 x28 / 16,9 x 30 / 18,4 x 38 simple-dual / 24,5 x 32
Front :
Rear:
Type:
Tires:
Rims:
Chassis
Type of chassis:
Operator´s Station
Type:
Steering:
Sensitive hydrostatic.
Cabin:
Pressurized, which prevents the entry of particles. With A/C cold/heat. Steering column: adjustable in height and depth, with two breaks, to obtain the best driving position.
Characteristics of the steering column:
Board:
Compact analog, with analog indicators of: engine rpm, cooling temperature, fuel level. Light indications: low oil pressure, clogged air filter, over coolant temperature, low fuel level, triggered hand brake, alternator failure, power take-off activated, lights.
Light switch:
Hermetic single control keyboard.
Seat:
Anatomical, with horizontal and vertical regulation by weight of the operator.
Theoretical Speeds
Dimensions
Axle spacing (mm):
2780
Total dimension (mm):
Total length (mm):
4572
Maximum height (mm):
3015
Max. dumping height (mm):
Dumping reach (mm):
Ground clearance (mm):
440
Height at the steering (mm):
2070
Minimum wheel track (mm):
Maximum wheel track (mm):
Maximum single wheel track (mm):
Front wheel track (mm):
2000 / 2100
Rear wheel track (mm):
1800 / 2200
Wheel track (mm):
Maximum width (mm):
Total width with single wheels (mm):
Total width with dual (mm):
Max single / dual width (mm):
2390 / 3410
Length with bucket (mm):
Total width (mm):
Maximum single / dual wheel track (mm):
Maximum wheel track with dual (mm):
2940
Maximum height at the steering (mm):
Travel Speed
Travel speed - Forward km/h):
Travel speed - Reverse (km/h):
Axles
Front axle:
Rear axle:
Front Loader Capacities
Bucket capacity - struck (m3):
Bucket capacity - heaped (m3):
Loading reach (m):
Dumping height (m):
Total operating height (m):
Turning angle (°):
Dumping angle (°):
Backhoe Capacities
Reach from central articulation (m):
Loading reach (m):
Operating height (m):
Digging depth (m):
Digging depth with flat bottom (m):
Arm folding force (kgf):
Turning arc (°):
Bucket penetration force (kgf):
Standard bucket width:
Loading height (m):
Operational Data
Transport height (m):
Transport width (m):
Transport length (m):
Axle spacing (m):
Cabin height (m):
Operating weight (kg):
Lights
Front Lights:
Rear Lights:
Attachment
Hydraulic lift
(Three point hitch):
(Three point hitch):
Drawbar:
Category:
Lower Boards:
Other
Traction:
Ballast:
Standard Equipment
Backup Camera:
Hydraulic decoupling of the bucket from the cab:
Lights for night work:
Air conditioning:
Third hydraulic way for bale spear:
Hydraulic joystick:
Tandem
Type:
Thickness (mm):
Chain drive step (mm):
Axle spacing (mm):
Oscillation (°):
Type of bearings:
Moldboard
Tipo:
Dimensiones (mm):
Presión máxima de la hoja (eq. estándar)(kg):
Alcance máximo por fuera de las ruedas (mm):
Ángulo máximo para corte de talud (°):
Operaciones:
Elevación de la cuchilla:
Desplazamiento lateral:
Inclinación de la hoja:
Máxima elevación sobre el suelo (mm):
Desplazamiento lat. del centro del circulo (mm):
Desplazamiento lat. de la vertedera (mm):
Cantoneras:
Rieles:
Scarifier
Number of teeth:
Working width (mm):
Drawbar:
Ripper:
Circle
Type:
External diameter (mm):
Rotation (continuous) (°):
Supports:
Thickness (mm):
Circle drive:
Frontal excavator blade
Type:
Compactor wheels
Type:
Extra Equipment
Mud scraper kit:
Full lower enclosure:
Hydraulic tank enclosure:
Optional Elements
3 point hydraulic lift:
Manual or automatic driver.
Rear hitch for trailer:
Yes.
Air conditioner:
Sunshade roof:
Closed cabin:
Hydraulic elevator:
Counterweight:
8
Hydraulic equipment:
Hydraulic equipment of Load Sensing closed center, with axial piston pump for variable flow and pressure. Max. working pressure (bar): 180. Work flow (l/min): 112 at 2500 rpm of the engine.
Drawbar:
