2200

Audaz Line

Audaz line adds to the field’s tasks a compact of strength and agility. Small in size but great in power, it is the ideal and reliable complement to develop the most difficult and demanding tasks.



It is equipped with Cummins engine, Load Sensing hydraulic system of PREMIUM character -recommended for direct seeding with latest generation machines-, maximum power of 220 HP, and a design that offers the best level of visibility, comfort and ergonomics.

More about this product

080077 PAUNY (72869)

Technical specifications

Engine

Brand/Model:
Cummins / 6BTA 5.9

Power:

Engine power at rated speed kw (HP):
164 (220)

Type:
Diesel 4 times.

Maximum rated speed (rpm):
2500

Maximum torque (Nm):
766

Maximum torque pattern (rpm):
1500

Number of cylinders:
6

Displacement (cm3):
5883

Aspiration:
Turbo supercharged post-cooled.

Diameter / Stroke (mm):
102 / 120

Compression ratio:
18:1

Injection:
Direct. Rotating pump.

Cooling system:
By liquid under pressure, with thermostat.

Starting system:
Electric 12 V, with ignition key.

Torque reserve (%):

Minimum consumption (g / kw.h):

Lubrication:

Air filter:

Exhaust system:

Transmission

Type:
Helical gears, synchronized.

Gearbox:
12 speeds forward and 4 backwards.

Front axle:
Directional, tractive.

Rear axle:
Electro-hydraulic drive lock.

Pressure of the steering system (mpa):

Speeds:

Brand:

Model:

Differential lock (NoSPin):

Torque ratio:

Maximum input speed (r.p.m.):

Maximum allowable engine torque (Nm):

Clutch

Type:
TDF: Wet multi-disc; Transmission: dual disc, dry.

Disc diameter: PTO / Transmission
- / 330

Hydraulic System

Type:
PREMIUM. Closed center (Load sensing), with double piston pump of 45 cm³/rev.

Maximum flow rate (l / min):
225 @ 2500 rpm.

Flow rate (l / min):

Maximum working pressure (bar):
180

Working pressure (Mpa):

Steering system pressure (Mpa):

Relief pressure:

Hydraulic outlets:
3 for double effect cylinders + 2 for hydraulic engines.

Fluid reservoir:
Independent.

Steering hydraulics:

Hydraulic cylinders:

Filter system:
Metallic suction filter and 2 micron paper filters in return.

Valve bank:

Electric System

Voltage (V):
12

Alternator (A):
12 V, 130 A.

Battery (Ah):
One (1) of 12 V and 180 Ah.

Power Take-Off

Type:
Independent, electro-hydraulic coupling.

PTO Speed:
540 and 1000

Drawbar:

Capacities and Weight

Fuel tank (reservoir) (l):
270

Tank with front PTO:

Auxiliary tank:

Hydraulic fluid tank (l):
123

Crankcase included oil filter (l):
14

Gearbox (l):

Rear differential (l):

Gearbox and rear differential (l):
130

Front differential (l):
9

Transmission (l):

Transmission (kg):

Transmission and rear differential (l):

Front axle (differential / hubs):

Weight without ballast in start command (kg):
7180

Weight with ballast with water in the covers and full fuel tank (kg):
9650

Nominal load (kg):

Operating weight (kg):

Bucket capacity (l):

Traction cycle time:

Maximum tractive force (kN):

Maximum displacement force:

Front wheel hub each (l):

Lubricant capacity (without radiator) (l):

Base machine weight (kg):

Front axle (kg):

Rear axle (kg):

Maximum weight (kg):

Total cycle time (s):

Articulation and Pivoting

Type:

Steering angle (°):

Articulation angle (°):

Minimum turning radius (mm):

Total pivoting angle (°):

Brakes

Service brakes:
Oil immersed discs, with independent or simultaneous pedal drive.

Parking brakes:
Oil immersed multiple discs, with mechanical drive.

Traction

Simple / Double:
Double.

Tire Sizes

Front / Rear:

Front :
16.9 x 30 / 420/85 R30

Rear:
30.5 L x 32 / 800/65 R32 / Opt.: 20.8 x 38 double.

Type:

Tires:

Rims:

Chassis

Type of chassis:

Operator´s Station

Type:

Steering:
Hydrostatics, sensitive (Load Sensing).

Cabin:
New design, more visibility. Pressurized with hot/cold air conditioning, hermetic, mounted on anti-vibration pads, with ergonomically well-positioned commands.

Characteristics of the steering column:

Board:
Instrumental compact, analog, with high resolution color TFT LCD display. Pointer indicators: tachometer, engine water temperature, fuel level and voltmeter; engine and gearbox oil pressure light alarms, critical engine water temperature, battery charge, air filter clogged, differential block, double traction coupled, handbrake, right - left turn, beacons, high light, fuel reserve.

Light switch:
Multi control key, hermetic.

Seat:
Anatomical, with longitudinal, vertical and by weight of the operator regulator.

Theoretical Speeds

Dimensions

Axle spacing (mm):
3050

Total dimension (mm):

Total length (mm):
5150

Maximum height (mm):
3260

Max. dumping height (mm):

Dumping reach (mm):

Ground clearance (mm):
500

Height at the steering (mm):
2070

Minimum wheel track (mm):

Maximum wheel track (mm):

Maximum single wheel track (mm):

Front wheel track (mm):
2100

Rear wheel track (mm):
2530

Wheel track (mm):

Maximum width (mm):

Total width with single wheels (mm):

Total width with dual (mm):

Max single / dual width (mm):

Length with bucket (mm):

Total width (mm):
2840

Maximum single / dual wheel track (mm):

Maximum wheel track with dual (mm):

Maximum height at the steering (mm):

Travel Speed

Travel speed - Forward km/h):

Travel speed - Reverse (km/h):

Axles

Front axle:

Rear axle:

Front Loader Capacities

Bucket capacity - struck (m3):

Bucket capacity - heaped (m3):

Loading reach (m):

Dumping height (m):

Total operating height (m):

Turning angle (°):

Dumping angle (°):

Backhoe Capacities

Reach from central articulation (m):

Loading reach (m):

Operating height (m):

Digging depth (m):

Digging depth with flat bottom (m):

Arm folding force (kgf):

Turning arc (°):

Bucket penetration force (kgf):

Standard bucket width:

Loading height (m):

Operational Data

Transport height (m):

Transport width (m):

Transport length (m):

Axle spacing (m):

Cabin height (m):

Operating weight (kg):

Lights

Front Lights:

Rear Lights:

Attachment

Hydraulic lift
(Three point hitch):

Drawbar:

Category:

Lower Boards:

Other

Traction:

Ballast:

Standard Equipment

Backup Camera:

Hydraulic decoupling of the bucket from the cab:

Lights for night work:

Air conditioning:

Third hydraulic way for bale spear:

Tandem

Type:

Thickness (mm):

Chain drive step (mm):

Axle spacing (mm):

Oscillation (°):

Type of bearings:

Moldboard

Tipo:

Dimensiones (mm):

Presión máxima de la hoja (eq. estándar)(kg):

Alcance máximo por fuera de las ruedas (mm):

Ángulo máximo para corte de talud (°):

Operaciones:

Elevación de la cuchilla:

Desplazamiento lateral:

Inclinación de la hoja:

Máxima elevación sobre el suelo (mm):

Desplazamiento lat. del centro del circulo (mm):

Desplazamiento lat. de la vertedera (mm):

Cantoneras:

Rieles:

Scarifier

Number of teeth:

Working width (mm):

Drawbar:

Ripper:

Circle

Type:

External diameter (mm):

Rotation (continuous) (°):

Supports:

Thickness (mm):

Circle drive:

Frontal excavator blade

Type:

Compactor wheels

Type:

Extra Equipment

Mud scraper kit:

Full lower enclosure:

Hydraulic tank enclosure:

Optional Elements

3 point hydraulic lift:

Rear hitch for trailer:

Air conditioner:

Sunshade roof:

Closed cabin:

Hydraulic elevator:

Counterweight:

Hydraulic equipment:

Drawbar:
